制成方式与产品结构
标准规范
主体材料 |
SUS304, SUS316L |
最大工作压力 |
600Psi |
表面处理 |
光面或喷砂外表面 |
<table style="border-width: 0px; border-style: solid; border-color: inherit; --tw-border-spacing-x: 0px; --tw-border-spacing-y: 0px; --tw-translate-x: 0; --tw-translate-y: 0; --tw-rotate: 0; --tw-skew-x: 0; --tw-skew-y: 0; --tw-scale-x: 1; --tw-scale-y: 1; --tw-pan-x: ; --tw-pan-y: ; --tw-pinch-zoom: ; --tw-scroll-snap-strictness: proximity; --tw-gradient-from-position: ; --tw-gradient-via-position: ; --tw-gradient-to-position: ; --tw-ordinal: ; --tw-slashed-zero: ; --tw-numeric-figure: ; --tw-numeric-spacing: ; --tw-numeric-fraction: ; --tw-ring-inset: ; --tw-ring-offset-width: 0px; --tw-ring-offset-color: #fff; --tw-ring-color: rgba(69,89,164,.5); --tw-ring-offset-shadow: 0 0 transparent; --tw-ring-shadow: 0 0 transparent; --tw-shadow: 0 0 transparent; --tw-shadow-colored: 0 0 transparent; --tw-blur: ; --tw-brightness: ; --tw-contrast: ; --tw-grayscale: ; --tw-hue-rotate: ; --tw-invert: ; --tw-saturate: ; --tw-sepia: ; --tw-drop-shadow: ; --tw-backdrop-blur: ; --tw-backdrop-brightness: ; --tw-backdrop-contrast: ; --tw-backdrop-grayscale: ; --tw-backdrop-hue-rotate: ; --tw-backdrop-invert: ; --tw-backdrop-opacity: ; --tw-backdrop-saturate: ; --tw-backdrop-sepia: ; text-indent: 0px; font-size: 0.875em; line-height: 1.71429; margin-bottom: 0.25rem; margin-top: 0.25rem; table-layout: auto; width: 613px; border-spacing: var(--tw-border-spacing-x) var(--tw-border-spacing-y); color: rgb(55, 65, 81); font-family: Söhne, ui-sans-serif, system-ui, -apple-system, " segoe="" ui",="" roboto,="" ubuntu,="" cantarell,="" "noto="" sans",="" sans-serif,="" "helvetica="" neue",="" arial,="" "apple="" color="" emoji",="" "segoe="" ui="" symbol",="" emoji";="" white-space-collapse:="" preserve;"="">
Model |
L
(mm) |
C
(mm) |
D
(mm) |
A
(in) |
B
(out) |
FR9-8040-V |
1301 |
1071 |
Φ203 |
1 1/2"-2" |
1" |
FR9-8080-V |
2317 |
2087 |
Φ203 |
1 1/2"-2" |
1" |
FR9-80120-V |
3333 |
3103 |
Φ203 |
1 1/2"-2" |
1" |
FR9-80160-V |
4349 |
4119 |
Φ203 |
1 1/2"-2" |
1" |
FR9-80200-V |
5365 |
5135 |
Φ203 |
1 1/2"-2" |
1" |
FR9-80240-V |
6381 |
6151 |
Φ203 |
1 1/2"-2" |
1" |
Model |
L
(mm) |
L1
(mm) |
D
(mm) |
A
(in) |
B
(out) |
FR9-8040-T |
1301 |
1071 |
Φ203 |
1 1/2"-2" |
1.5" |
FR9-8080-T |
2317 |
2087 |
Φ203 |
1 1/2"-2" |
1.5" |
FR9-80120-T |
3333 |
3103 |
Φ203 |
1 1/2"-2" |
1.5" |
FR9-80160-T |
4349 |
4119 |
Φ203 |
1 1/2"-2" |
1.5" |
FR9-80200-T |
5365 |
5135 |
Φ203 |
1 1/2"-2" |
1.5" |
FR9-80240-T |
6381 |
6151 |
Φ203 |
1 1/2"-2" |
1.5" |
